Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
1 / 5
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator
Multi-Purpose Residential Building Passenger Freight Construction Elevator

Multi-Purpose Residential Building Passenger Freight Construction Elevator

Customization: Available
After-sales Service: Provided
Warranty: 1year
Send Inquiry

Product Description

Basic Information
Model NO.
SC200/200
Type
Construction Elevator
Load Capacity
1T - 2T
Speed
20M/Min - 40M/Min
Usage
Construction Hoist
Lift Drive
Electric Motor
Transport Package
Bulk
HS Code
8428909090
Production Capacity
1,000 Sets/Year
Product Features
  • The cage drive system is equipped with a buffering device for stable movement.
  • Ergonomically designed cage interior for improved operator comfort.
  • Unique structural design with applied patent technology.
  • Advanced typical technologies ensure guide rail precision.
  • Industry-leading components ensure reliable machine quality.
  • Precise assembly processes and accurate drive mechanisms.
  • Professional solutions tailored for special construction projects.
  • Comprehensive safety devices ensure a reliable control system.
Technical Specifications
Model Unit SC200/200 SC200/200BP SCD200/200 SC200/200B
Configuration - Standard type Frequency conversion Counterweight type Export type
Rated load kg 2000/2000 2000/2000 2000/2000 2000/2000
Cage size L× W× H m 3× 1.3× 2.2 3× 1.3× 2.2 3× 1.3× 2.2 3× 1.3× 2.2
Passengers - 16/16 16/16 16/16 16/16
Max. lifting height m 150 300 150 150
Lifting speed m/min 33 0~60 33 33
Std. section Size mm 650× 650× 1508
Electric motor Type - Disc brake electric motor
Power kW 11× 3/11× 3 11× 3/11× 3 11× 2/11× 2 11× 3/11× 3
Product Display
Passenger Freight Construction Elevator 1
Passenger Freight Construction Elevator 2
Passenger Freight Construction Elevator 3
Passenger Freight Construction Elevator 4
Frequently Asked Questions
What is the maximum load capacity of the SC200/200 model?
The rated load capacity for the SC200/200 series is 2000kg per cage, suitable for both passengers and freight.
What lifting speeds are available for this construction elevator?
Standard models offer a speed of 33m/min, while frequency conversion (BP) models can reach speeds from 0 to 60m/min.
Is the cage drive system safe for high-rise projects?
Yes, the system is equipped with buffering devices and a complete set of safety limiters to ensure reliable control and stability.
What is the maximum lifting height the SC200/200BP can reach?
The frequency conversion (BP) model is designed for high-rise applications with a maximum lifting height of up to 300 meters.
What kind of motors are used in these hoists?
We utilize high-quality disc brake electric motors, typically in configurations of 11kW x 3 or 11kW x 2 depending on the model.
Can the cage size be customized for special projects?
While our standard cage size is 3m × 1.3m × 2.2m, we provide professional solutions and adjustments for special project requirements.
